12V Waterproof SUS430 ABS Solenoid Cabinet Lock
Product parameters:
| Model | KR-S99S |
| Size | 98.9*67.5*13.8 mm |
| Name | Outdoor Intelligent Solenoid 12V Cabinet Door Lock |
| The material of the lock body | 430 Stainless steel+PA+GF |
| The material of the lock bolt | Zinc alloy nickel plating |
| Working voltage | DC12V/DC24V |
| Working current | 2.4A/1.2A |
| Maximum power | 28W |
| Response time | Less than 20ms |
| Working temperature | -20℃ ~ +60℃ |
| Working humidity | 5% ~ 85%RH |
| Working life | 500,000 times |
| Door weight | 0.5KG~10KG |
| Test | Salt spray testing 48 hours |
| Usage | locker; express cabinet; vending machine; gym lockers |
| Certification | CE; FCC; RoHS |
| OEM | Accepted |
Product Main Features:
1. Solenoid driven, support 12V & 24V.
2. 430 stainless steel shell, anti-force performance as 300kgs.
3. Lock hook detection function.
4. All electronic parts are protected in the sealed ABS box. Can be waterproof.
5. Built-in push block helps push the door, thrust can be adjusted.
6. With mechanical emergency lever, can be unlocked manually when power cut.
7. AWG24 wires with PVC protecting tube.
8. Push door detection function.
9. Support custom terminals and wires.
Product Details:
Product Applications:
Our products KR-S99S solenoid cabinet door locks are used in freezers, parcel cabinets, storage cabinets, etc.
Hot Tag: Solenoid Driven12V Lock, Outdoor Waterproof Locker Lock, Electromagnetic Logistic Cabinet
